Micro 6volt N20 DC Gear Motor Carbon Brushed 60rpm Permanent Magnet
Product Details:
| Place of Origin: | China |
| Brand Name: | Kind Motor |
| Certification: | ISO9001/RoHS/CE |
| Model Number: | KGM12-N30 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | $1.8-$3.5/PCS |
| Packaging Details: | Expect Standard Carton and Foam |
| Delivery Time: | 1-6 weeks |
| Payment Terms: | L/C, D/A, D/P, T/T,Paypal, Western Union |
| Supply Ability: | 500000/Month |
|
Detail Information |
|||
| Voltage(v): | 1.5volt～24volt | Speed(rpm): | 3rpm～6000rpm |
|---|---|---|---|
| Gears Material: | Stainless Steel | Brush Type: | Metal Brushes/Carbon Brushes |
| Type: | Reduction Motor | Torque: | ≤3Kg.cm |
| Construction: | Permanent Magnet | Continuous Current(a): | ≤2A |
| Output Power: | ≤2W | Weight: | 10.6g |
| High Light: | 6volt N20 DC Gear Motor,Permanent Magnet N20 DC Gear Motor,60rpm Reduction Gear Motor |
||
Product Description
Micro GM12-N10 N20 N30 10*12mm carbon brush low speed 60rpm 100rpm dc 1.5v 3v 5v 6volt 12v micro gear door lock motor for robot
Product introduction
This is dc brushes motor with diameter 10×12mm spur all metal reduction gearbox,the gearbox
have 5:1 10:115:1 30:1 50:1 75:1 100:1 150:1 210:1 250:1 298:1 380:1 422:1 600:1 1000:1
reduction ratio,it's can with four type motors(N10,N20,N30,N50),they have same diameter
different length,longer length have higher torque,the motor have metal brush and carbon brush,
carbon brush have longer lifetime,you choode different reduction ratio and motor,the speed and
torque is different.
Brand:Kind Motor
| Model | KGM12-N30 |
| Gears Material | Stainless steel |
| Gearbox Reduction ratio | 5:1～1000:1 |
| Motor model | N10 ,N20 ,N30 and N50 Brushes Motor |
| Brush Type | Precious Metal-Brushed/Carbon-Brushed |
| Voltage | 1.5v,3v,3.7v 4.5v,5v,6v,7.4v,8v,9v,12v,24v |
| Speed | 3rpm-6000rpm |
| Rated Torque |
＜200mNm
|
| Shaft Size | 3mm D shaft |
| Typical Application |
Smart Lock, Robot, Electric Valve,Toy,Massage instrument,
Electric screwdriver,3D printing pen,Beauty equipment,etc.
|
Product Parameters
█ODM & OEM
█If you need other size and patameters,diameter from 6mm~60mm can be chosen
█The parameters and shaft size can customized
DC N20 Metal-brush motor with spur 10*12mm all metal reducer gearbox
DC N20 Carbon-brush motor with spur 10*12mm all metal reducer gearbox
DC N30 Metal-brush motor with spur 10*12mm all metal reducer gearbox
DC N30 Metal-brush motor with spur 10*12mm all metal reducer gearbox
